Product Information |
Document ID: DDSE-44SKC2 |
3519 Rack Storage Expansion Enclosure - Expansion Bays
Applicable to: World-Wide
|
Bay |
Drive Width |
Drive Type |
Drive Height |
|
1 - 3 |
3.5-inch |
Removable media drive (1), hard disk drive (2) |
41.3 mm (1.6 in.) |
|
4 - 9 |
3.5-inch |
Hot-Swap (3) |
25.4 mm (1.0 in.) |
Notes:
1. Removable media includes CD-ROMs, optical discs, and tape.
2. You can install a maximum of two 41.3 mm drives. If two 41.3 mm drives are installed in the non-hot-swap bays, they must be in bays 1 and 3 to allow adequate airflow across the drives.
3. A 41.3 mm drive installed in bays 4 through 9 occupies two bays.
|
