Parts Information |
Document ID: JBAR-3TQSF7 |
IBM PC300PL (Type 6892) - Parts diagram/FRU listing
Applicable to: World-Wide
|
Index |
System (Type 6892) |
FRU No. |
|
1 |
Cover and Handle |
12J4494 |
|
2 |
Power Switch/LED Cable Assembly |
12J4510 |
|
3 |
Top Cover Assembly |
12J4509 |
|
4 |
Front Bezel |
12J4495 |
|
|
(Order either 32X Max CD-ROM drives) | |
|
5 |
CD-ROM (32X Max) |
02K1115 |
|
5 |
CD-ROM (32X Max) |
02K3412 |
|
|
CD-ROM Audio Cable |
75H9219 |
|
6 |
4.2 GB EIDE Hard Disk Drive |
10L6011 |
|
6 |
6.4 GB EIDE Hard Disk Drive |
10L6012 |
|
|
Hard Disk Cable, EIDE |
12J4518 |
|
6 |
4.5 GB SCSI Hard Disk Drive |
10L6084 |
|
|
SCSI Adapter Card - Adaptec |
10L7095 |
|
|
SCSI Data Cable |
01K1467 |
|
|
SCSI LED Cable |
76H7344 |
|
7 |
1.44 MB, 3.5-Inch Diskette Drive |
75H9550 |
|
7 |
1.44 MB, 3.5-Inch Diskette Drive-Japan |
75H9552 |
|
|
Diskette Drive Cable |
76H7340 |
|
8 |
Louver Blank Bezel |
01K1889 |
|
|
Miscellaneous Optional Bezel |
12J4498 |
|
9 |
3.5-inch Front Panel |
01K1854 |
|
10 |
Model Plate |
12J4499 |
|
11 |
RFID Antenna |
03K9769 |
|
12 |
Bottom cover |
03K9602 |
|
13 |
Foot (4) |
12J6294 |
|
14 |
System Board Latch and Screw |
01K1612 |
|
15 |
Memory - 32 MB DIMM, EDO ECC |
01K1143 |
|
15 |
Memory - 32 MB DIMM, Non-Parity |
01K1146 |
|
15 |
Memory - 64 MB DIMM, EDO ECC |
01K1140 |
|
15 |
Memory - 64 MB DIMM, Non-Parity |
01K1147 |
|
16 |
Processor Pentium II 266 MHz |
01K2169 |
|
16 |
Processor Pentium II 300 MHz |
01K4291 |
|
16 |
Processor Pentium II 333 MHz ECC |
01K4327 |
|
16 |
Processor Pentium II 350 MHz |
01K4333 |
|
16 |
Processor Pentium II 400 MHz |
01K4334 |
|
16 |
Processor Pentium II 450 MHz |
01K1578 |
|
17 |
System Board (no proc., memory, rails) |
11L1619 |
|
|
System Board Rail Set |
03K9626 |
|
18 |
Fan Bracket |
03K9606 |
|
19 |
60 mm Fan with rubber mounts (Open Bay, AAP models only) |
10L5513 |
|
19 |
92 mm Fan with rubber mounts |
02K2861 |
|
20 |
Speaker/Card Guide Assembly |
03K9605 |
|
21 |
EMC Kit |
12J4508 |
|
22 |
Access Cover Assembly |
12J4493 |
|
23 |
C2 Switch Cable Assembly |
01K1495 |
|
24 |
AGP Cover |
03K9623 |
|
25 |
Hard Disk Drive Bracket |
03K9608 |
|
26 |
I/O Clamp |
03K9604 |
|
27 |
Power Supply (200W) |
75H8991 |
|
27 |
Power Supply (200W) - Japan |
76H4873 |
|
28 |
Keylock Assembly |
12J5102 |
|
29 |
Base Frame Assembly |
03K9609 |
|
Cable - Wake On Ring |
76H7345 | |
|
Lithium Battery |
33F8354 | |
|
Miscellaneous Hardware Kit |
03K9603 | |
|
Miscellaneous Screw Kit |
93F0041 | |
|
Processor Mounting Bracket Kit (for all above processors) |
33L4321 | |
|
Retention Module (RM) adapter (for Celeron and Pentium II processors only) |
33L4320 | |
|
Riser Card |
61H2331 | |
|
Riser Supports (front and rear) |
02K2766 | |
|
Speaker Assembly |
03K9607 |
|
