IBM IntelliStation M Pro (Type 6889) - Parts diagram/FRU listing
Applicable to: World-Wide
Type 6889 Parts:
Parts Listing:
|
Index |
System (Type 6889) |
FRU No. |
|
1 |
Handle/Cap Assembly |
12J5547 |
|
2 |
Power switch/LED Cable Assembly |
12J4510 |
|
3 |
Top/Side Cover Assembly |
01K1637 |
|
4 |
CD-ROM Drive 32X Max |
02K1119 |
|
5 |
6.4 GB IDE Hard Disk Drive, 7200 RPM |
10L6078 |
|
5 |
9.1 GB IDE Hard Disk Drive, 7200 RPM |
10L6079 |
|
5 |
4.5 GB SCSI Hard Disk Drive, |
10L6084 |
|
5 |
9.1 GB SCSI Hard Disk Drive, 7200 RPM |
10L6085 |
|
5 |
9.1 GB SCSI Hard Disk Drive, 10,000 RPM |
10L6016 |
|
5 |
10.1 GB IDE Hard Disk Drive, 7200 RPM |
10L6063 |
|
6 |
3.5-In. 1.44 MB Diskette Drive |
75H9550 |
|
6 |
3.5-In. 1.44 MB Diskette Drive - Japan |
75H9552 |
|
7 |
Blank Louver Bezels (3.5-In. and 5.25-In.) |
01K1888 |
|
|
Miscellaneous Optional Blank Bezels |
12J5551 |
|
|
CD-ROM Picture Frame Bezel |
12J6473 |
|
8 |
3.5-In. Bezel Assembly |
12J5549 |
|
9 |
Model Plate |
12J5552 |
|
10 |
RFID Antenna |
03K9769 |
|
11 |
Front Bezel |
12J5548 |
|
12 |
System Board-without processor or memory |
93H9345 |
|
13 |
Fan Assembly 92 mm |
02K2861 |
|
14 |
Card Guide |
10L5607 |
|
15 |
C2 Switch Assembly |
01K1495 |
|
16 |
EMC Kit |
12J4508 |
|
17 |
3.5/5.25-In. Hard Disk Bracket |
12J4501 |
|
18 |
Access Cover Assembly |
12J5546 |
|
19 |
Video Adapter - Matrox Eclipse |
01K4422 |
|
19 |
Video Adapter - Matrox Millenium |
01K4340 |
|
19 |
Video Adapter - 3D PRO 3400/GA |
01K4337 |
|
19 |
Video Adapter - 3D PRO 3400/T |
01K4336 |
|
19 |
Video Adapter - Permedia 2A |
28L4968 |
|
20 |
Air Baffle |
02K2864 |
|
21 |
3.5-In. Hard Disk Bracket |
12J4516 |
|
22 |
64 MB ECC DIMM Memory |
01K1140 |
|
22 |
128 MB ECC DIMM Memory |
01K1141 |
|
22 |
256 MB ECC DIMM Memory |
01K1142 |
|
23 |
350 MHz Pentium II microprocessor |
01K4333 |
|
23 |
400 MHz Pentium II microprocessor |
01K4334 |
|
23 |
450 MHz Pentium II microprocessor |
01K1578 |
|
|
Terminator Card, Processor |
01K7349 |
|
|
Processor Retainer Support Bracket Assembly |
02K2903 |
|
24 |
Power Supply 330 W. |
01K9866 |
|
25 |
Keylock Assembly |
12J5102 |
|
26 |
Chassis Assembly |
12J4515 |
|
Cable - Audio CD-ROM |
75H9219 | |
|
|
Cable - CD-ROM IDE |
01K1483 |
|
|
Cable - Diskette Drive |
01K1541 |
|
|
Cable - Hard Disk IDE |
01K1553 |
|
|
Cable - Intergraph |
01K2035 |
|
|
Cable - SCSI 2 Drop |
01K1485 |
|
|
Cable - SCSI 4 Drop |
01K1481 |
|
|
Foot (Qty 4) |
12J4506 |
|
|
Microphone |
01K4910 |
|
|
Miscellaneous Hardware Kit |
12J4503 |
|
|
Miscellaneous Screw Kit |
93F0041 |
|
|
Speaker |
06H9417 |
|
|
System Board EMC Shield |
01K1855 |
|
