IBM ValuePoint - Type 64xx memory
Applicable to: World-Wide
Memory:
Computer Memory:
Four 72-pin connectors are available to add memory modules. Memory modules supported are 4MB, 8MB, 16MB, and 32MB with a maximum of 128MB. Memory module speed supported is 70 ns.
Notes:
1. QAPlus/WIN for ValuePoint and most applications do not recognize more than 64MB of memory.
2. A memory module must be installed in memory module connector 1 at all times. Additional memory modules must be installed in connector 2, then in connector 3, then in connector 4.
3. Smaller size memory modules must be installed into lower numbered memory module connectors. For example, to install two 4MB memory modules with two 8MB memory modules, the 4MB memory modules must be installed in memory module connectors 1 and 2 and the 8MB memory modules in memory module connectors 3 and 4.
ValuePoint Memory Module Chart:
FRU |
Size |
6 |
6 |
6 |
6 |
P |
6 |
6 |
60G2950 |
16-70ns |
X |
X |
X |
X |
X |
X | |
64F3606 |
8-70ns |
X |
X |
X |
X | |||
64F3607 |
8-80ns |
X |
X |
X |
X | |||
73G3233 |
4-70ns |
X |
X |
X | ||||
73G3234 |
8-70ns |
X |
X | |||||
73G3235 |
32-70ns |
X | ||||||
92F0102 |
2-70ns |
X |
X |
X |
X | |||
92F0103 |
2-80ns |
X |
X |
X |
X | |||
92F0104 |
2-85ns |
X |
X |
X |
X | |||
92F0105 |
4-70ns |
X |
X |
X |
X | |||
92F3337 |
4-80ns |
X |
X |
X |
X | |||
93F0058 |
1-80ns |
X | ||||||
96F9289 |
4-80ns |
X | ||||||
71G0801 |
32-70ns |
X |
