IBM IntelliStation Z Pro (Type 6865) - Parts Diagram/Listing
Applicable to: World-Wide
|
Index |
System (Type 6865) |
FRU No. |
|
1 |
Handle/Cap Assembly |
12J5547 |
|
2 |
Power Switch/LED Cable Assembly |
02K1414 |
|
3 |
Top/Side Cover Assembly |
01K1637 |
|
4 |
CD-ROM Drive 32X Max |
02K3414 |
|
5 |
9.1 GB LVD SCSI Hard Disk Drive,10,000 RPM |
10L6016 |
|
5 |
4.5 GB LVD SCSI Hard Disk Drive, 7,200 RPM |
10L6084 |
|
6 |
3.5-In. 1.44 MB Diskette Drive |
75H9550 |
|
6 |
3.5-In. 1.44 MB Diskette Drive - Japan |
75H9552 |
|
7 |
Blank Louver Bezels |
01K1888 |
|
Miscellaneous Optional Bezels |
12J5551 | |
|
8 |
3.5-In. Bezel Assembly |
12J5549 |
|
9 |
Name Plate |
10L5597 |
|
10 |
RFID Antenna |
03K9654 |
|
11 |
Front Bezel |
12J5596 |
|
12 |
Fan Assembly 92 mm |
02K2861 |
|
13 |
System Board-without processor or memory |
01K4345 |
|
14 |
Speaker |
01K4909 |
|
15 |
Card Guide |
10L5592 |
|
16 |
Fan Assembly, front, 120x25 mm |
10L5594 |
|
17 |
C2 Switch Assembly |
10L5595 |
|
18 |
Support Bracket |
10L5626 |
|
19 |
Access Cover Assembly |
12J5546 |
|
20 |
LVD SCSI Adapter - Adaptec 2940 U2W |
10L7122 |
|
20 |
Video Adapter - Eclipse |
01K4422 |
|
20 |
Video Adapter - Matrox Millenium |
01K4340 |
|
20 |
Video Adapter - 3D PRO 3400/GA |
01K4337 |
|
20 |
Video Adapter - 3D PRO 3400/T |
01K4336 |
|
21 |
Air Baffle |
10L5598 |
|
22 |
Fan Assembly, rear, 120x38 mm |
10L5593 |
|
23 |
3.5-In. Hard Disk Bracket |
10L5591 |
|
24 |
128 MB ECC DIMM Memory |
01K1156 |
|
24 |
256 MB ECC DIMM Memory |
01K1142 |
|
25 |
400 MHz Pentium II Xeon microprocessor |
01K4349 |
|
25 |
450 MHz Pentium II Xeon microprocessor |
01K4434 |
|
26 |
Terminator Card, Processor |
94H0598 |
|
Voltage Regulator Module (VRM), for second processor |
20L2318 | |
|
Processor Retainer Support Bracket Assembly |
10L5599 | |
|
27 |
Power Supply 330 W. |
20L2316 |
|
28 |
Keylock Assembly |
12J5102 |
|
29 |
Chassis Assembly, with support bracket |
10L5589 |
|
Cable - Audio CD-ROM |
75H9219 | |
|
Cable - CD-ROM IDE |
01K1548 | |
|
Cable - Diskette Drive |
01K1546 | |
|
Cable - Hard Disk IDE |
01K1547 | |
|
Cable - Intergraph |
01K2035 | |
|
Cable - LVD SCSI 5 Drop |
01K1549 | |
|
Cable - SCSI LED |
76H7344 | |
|
Cable - Wake on LAN |
76H7345 | |
|
EMC Kit |
10L5590 |
|
