Parts Information |
Document ID: BMOE-3YBQR5 |
TP 560Z - Common FRU parts
Applicable to: World-Wide
|
Miscellaneous Parts | |
|
Screw Kit includes: |
05K5725 |
|
M2.5 x 6, Flat Head (9) | |
|
M2.5 x 3, Flat Head (1) | |
|
M2.5 x 4.8, Flat Head (1) | |
|
Hex Stud (6) | |
|
M2.5 x 6, Bind (Black) (19) | |
|
M2.5 x 8, Bind (Black) (7) | |
|
M2 x 6, Bind (4) | |
|
M2 x 18, Bind (3) | |
|
M2.5 x 22, Bind Nylock (2) | |
|
M2.5 x 12, Bind Nylock (3) | |
|
M2.6 x 4, Bind (Yellow) (1) | |
|
M2.6 x 2.8, Bind (Red)(3) | |
|
M2 x 1.7, Special Pan (Blue) (4) | |
|
M2 x 2.4, Special Pan (Yellow) (2) | |
|
M3 x 3, Flat (4) | |
|
M2.5 x 6, Special (1) | |
|
M2.5 x 6, Big Head (Yellow) (1) | |
|
M2.5 x 25, Bind Nylock (1) | |
|
Option Parts | |
|
Notes | |
|
2. The warranty for the system unit does not apply to all options. | |
|
Headset |
85G1529 |
|
6.4GB HDD Assembly |
02K0520 |
|
AC Adapter (56 W, 3-prong)1 |
02K7007 |
|
AC Adapter (56 W, 3-prong)1 |
02K7011 |
|
AC Adapter (for Japan, 2-prong)2 |
11J8974 |
|
AC Adapter (for Japan, 2-prong)2 |
02K6497 |
|
Microphone |
66G7871 |
|
PS/2 Miniature Mouse |
95F5723 |
|
ThinkPad Port Replicator with Advanced EtherJet Feature Box Assembly |
05K4874 |
|
Upper Cover Assembly |
05K4875 |
|
ThinkPad 560 Port Replicator I |
05K4645 |
|
DIMM 16MB (60 ns) |
01K1115 |
|
DIMM 32MB (60 ns) |
42H2769 |
|
DIMM 64MB (60 ns) |
42H2817 |
|
Interface Cable to System for Keyboard |
84G2531 |
|
Interface Cable to Keyboard for Keypad |
84G2532 |
|
Mini-DIN to Mini-DIN Cable |
84G6474 |
|
Numeric Keypad | |
|
Belgian |
95F5741 |
|
Canadian French |
95F5466 |
|
Danish |
95F5467 |
|
Dutch |
95F5467 |
|
French |
95F6313 |
|
German |
95F6314 |
|
Greek |
95F5467 |
|
Hebrew |
95F5741 |
|
Icelandic |
95F5467 |
|
Italian |
95F6316 |
|
Japanese |
79F6401 |
|
Norwegian |
95F5467 |
|
Spanish |
95F6315 |
|
Swedish or Finnish |
95F5468 |
|
Swiss French |
95F5711 |
|
Swiss German |
95F5715 |
|
Turkish |
95F5467 |
|
U.K. English |
95F5741 |
|
U.S. English |
95F5741 |
|
Black Keypad | |
|
French |
84G6286 |
|
Germain |
84G6280 |
|
Italian |
84G6292 |
|
Norwegian |
84G6310 |
|
Swedish |
84G6304 |
|
U.K. English |
84G6298 |
|
U.S. English |
84G2530 |
|
Black Keyboard | |
|
French |
84G6285 |
|
German |
84G6279 |
|
Italian |
84G6291 |
|
Norwegian |
84G6309 |
|
Swedish |
84G6303 |
|
U.K. English |
84G6297 |
|
U.S. English |
84G2529 |
|
Accessories | |
|
Keyboard/Mouse Cable |
54G0444 |
|
Tools | |
|
Tri-Connector Wrap Plug |
72X8546 |
|
PC Test Card |
35G4703 |
|
USB Parallel Test Cable |
05K2580 |
|
Screwdriver Kit |
95F3598 |
|
Torque Screwdriver |
05K4695 |
|
5-mm Socket Wrench |
05K4694 |
|
Screwdriver |
05K4693 |
|
Search Keywords |
| |
|
Document Category |
Hardware Maintenance Information | |
|
Date Created |
14-09-98 | |
|
Last Updated |
19-01-99 | |
|
Revision Date |
19-01-2000 | |
|
Brand |
IBM ThinkPad | |
|
Product Family |
ThinkPad 560Z | |
|
Machine Type |
2640, 2641 | |
|
Model |
Various | |
|
