Service Hints & Tips |
Document ID: GCOR-38ZL5V |
Aptiva - Mwave card jumpers and connectors
Applicable to: World-Wide
Mwave Card:
Mwave Card (Combination Modem/Sound)
NOTE: This is a common layout of Mwave cards; therefore, not all jumpers listed will be present or functional.
Mwave Jumpers and Connectors:
P1 (CD-ROM2/TV card)
P3 (CD-ROM1)
P4, P5 (I/O Address):
P4 and P5 are jumpered to I/O address CE3O. The I/O jumper setting can be changed to correct conflicts with other cards using I/O addresses or Joystick port settings.
Short the top pin to middle pin for jumper position A.
Short the bottom pin to middle pin for jumper position B.
|
To Select I/O Address: |
Set P4 to: |
Set P5 to: |
|
CE30 |
Position B |
Position B |
|
01B0 |
Position A |
Position B |
|
0130 |
Position A |
Position A |
P7 (Wake Up On Ring)
P9 (Unused)
P10 (Joystick Enable/Disable)
Short P10 to enable the Joystick.
Open P10 to disable the Joystick
|
Search Keywords |
| |
|
Hint Category |
Jumper/Switch Settings, Mwave | |
|
Date Created |
27-08-96 | |
|
Last Updated |
15-03-99 | |
|
Revision Date |
15-03-2000 | |
|
Brand |
IBM Aptiva | |
|
Product Family |
Aptiva | |
|
Machine Type |
2134, 2144, 2168, 2176 | |
|
Model |
C23; C31; C32; C33; C35; C3X; C53; C55; C5X; C65; C66; C67; C6B; C6D; C6E; C6X; C6Y; C73; C77; C7X; 6R8; 6R9; 7R0; 7R1; 7R2; 7R3; 7R6; 7R7; 7R9; 8R1; 8R6; 8R8; 9R2; 9R3; 9R4; 9R5; 9R6; F23; F31; F32; F33; F35; F67; F6B; M40; M41; M53; M54; M55; M56; M57; M58; M60; M61; M62; M70; M71; M72; M91; A40; A44; A45; A50; A51; A52; A90; A92; A94; 2R6; 3R5; 4R2; 4R7; 2R9; 3R3; 3R1; 4R8; 3R0; 3R7; 4R0; 4R9; 3R8; 3R9; 4R3; 5R5; C40; C41; C45; C53; C61; M30; M31; M35; M50; M51; M52; M63; A10; A12; A14; 2R0; 2R3; 2R0; 2R3; 2R5; 2R7; 2R8; 3R4; 3R6; 4R1; 5R1; 6R3; C30; C31; C51; C21; 6R6; 132; 142; 152; 154; 162; 163; 172; 182; L15; L16; K25; K26; L33; K33; L43; K43; L35; K35; L45; K45; KU5; L55; K55; L65; K65; L66; K66; U15; U16; U33; U43; U35; U45; U55; U65; U66; X17; X27; X37; X47; Y17; Y27; Y37; Y47; Z17; Z27; Z37; Z47; S55; S65; S64; S74; S75; W37; W47; S20; 932; 9W2; LL5; LL6; L50; L60; K50; K60; LL1; LL2; LL3; LL4; L10; L20; L30; L40; K10; K20; KU6; K30; K40; KU4; X40; Y40; Z40; N50; N51; N60; N61; N71; Y10; Y20; Y30; Z10; Z20; Z30; X10; X20; X30; W30; N30; N40; N41; 352; 354; 355; 356; 357; 362; 363; 364; 372; 374; 381; 382; 384; 392; 442; 443; 447; 449; 454; 6R8; 6R9; 7R0; 7R1; 7R2; 7R3; 7R6; 7R7; 7R9; 8R1; 8R6; 8R8; 9R1; 9R3; 9R4; 9R5; 9R6; C23; C31; C32; C33; C35; C3X; C53; C55; C5X; C65; C66; C67; C6B; C6D; C6E; C6X; C6Y; C6Z; C73; C77; C7X; F23; F31; F32; F33; F35; F67; F6B; H54; H55; H56; H5E; H5F; H64; H65; H6D; H6E; H6F; H7E; H7F; H7G; J33; J35; J3C; J3E; J3K; J3L; J3V; J3W; J3Y; J3Z; JCL; K53; J62; K74; L53; L62; P53; P62; T01; T33; T34; T62; T63; T65; T71; V34; V65; V71; W33; W55; W65; X01; X31; X33; X34; X52; X62; X63; X65; X71; Y01; Y04; Y31; Y33; Y34; Y52; Y62; Y63; Y65; Y71; Z01; Z31; Z33; Z34; Z52; Z62; Z63; Z65; Z71; 446; 6R6; C21; J31; J3A; J3X; J51; J52; JDA; JSN; K01; K21; K22; K23; K31; K32; K52; L01; L21; L22; L23; L31; L32; L52; L6T; P01; P21; P22; P23; P31; P32; P52 | |
|
