Service Hints & Tips |
Document ID: GCOR-38ZL5E |
Aptiva - EMEA Mwave card jumpers & connectors
Applicable to: World-Wide
EMEA Mwave Card:
EMEA Mwave Card (Combination Modem/Sound)
EMEA Mwave Jumpers and Connectors
P3 (CD-ROM1)
P4, P5 (I/O Address):
P4 and P5 are jumpered to I/O address CE3O. The I/O jumper setting can be changed to correct conflicts with other cards using I/O addresses or Joystick port settings.
Short the top pin to middle pin for jumper position A.
Short the bottom pin to middle pin for jumper position B.
|
To Select I/O Address: |
Set P4 to: |
Set P5 to: |
|
CE30 |
Position B |
Position B |
|
01B0 |
Position A |
Position B |
|
0130 |
Position A |
Position A |
P7 (Wake Up On Ring)
P8 (Unused)
P9 (Unused)
P10 (Joystick Enable/Disable)
Short P10 to enable the Joystick.
Open P10 to disable the Joystick
|
