Service Hints & Tips |
Document ID: LWIK-3XZKX9 |
TP 560Z - 1120 Fan
Applicable to: World-Wide
The following information is intended for IBM Dealers and Authorized Servicers only. Customers attempting to follow any of the procedures below may void their warranty.
Battery Pack (1030)
Keyboard Bezel (1050)
Heat Sink (1100)
Apply grease (0.2 grams) over the module. Refer to step 5 on page 60 for the location of the module.
Notes:
1. Do not touch the rotor or the blade of the fan when assembling or disassembling. You may break it.
2. Do not pinch the fan cable when re-installing the fan.
|
